SPECIFICATION
|
|
|
|
|||
|
ITEM
|
Z5032C
|
Z5040C
|
Z5045C
|
|||
|
|
|
|
|
|||
|
Max.drilling capacity
|
32mm
|
40mm
|
45mm
|
|||
|
Spindle taper
|
M.T.3 or R8
|
M.T.4
|
M.T.4
|
|||
|
Spindle travel
|
130mm
|
130mm
|
130mm
|
|||
|
Step of spindle speed
|
6
|
6
|
6
|
|||
|
Range of spindle speed 50Hz
|
80-1250 r.p.m
|
80-1250 r.p.m
|
80-1250 r.p.m
|
|||
|
60Hz
|
95-1500 r.p.m
|
95-1500 r.p.m
|
95-1500 r.p.m
|
|||
|
Min.distance from spindle axis to column
|
283mm
|
283mm
|
283mm
|
|||
|
Max.distance from spindle nose to worktable
|
700mm
|
700mm
|
700mm
|
|||
|
Max.distance from spindle nose to stand table
|
1125mm
|
1125mm
|
1125mm
|
|||
|
Max.travel of headstock
|
250mm
|
250mm
|
250mm
|
|||
|
Swivel angle of headstock(horizontal/perpendicular)
|
360°/±90°
|
360°/±90°
|
360°/±90°
|
|||
|
Max.travel of worktable bracket
|
600mm
|
600mm
|
600mm
|
|||
|
Table size
|
730×210mm
|
730×210mm
|
730×210mm
|
|||
|
Size of stand worktable of avaliability
|
417×416mm
|
417×416mm
|
417×416mm
|
|||
|
Forward and afterward travel of worktable
|
205mm
|
205mm
|
205mm
|
|||
|
Left anf right travle of worktable
|
500mm
|
500mm
|
500mm
|
|||
|
Vertical travel of worktable
|
570mm
|
570mm
|
570mm
|
|||
|
Motor Power
|
0.75KW(1HP)
|
1.1KW(1.5HP)
|
1.5KW(2HP)
|
|||
|
Voltage/Frequency
|
As customer's requirement
|
|
|
|||
|
speed of motor
|
1400 r.p.m
|
1400 r.p.m
|
1400 r.p.m
|
|||
|
Net weight/Gross weight
|
430kg/500kg
|
432kg/502kg
|
435kg/505kg
|
|||
|
Packing size
|
1850×750×1000mm
|
1850×750×1000mm
|
1850×750×1000mm
|
|||
|
Loading amount
|
18pcs/20＇container
|
18pcs/20＇container
|
18pcs/20＇container
|
|||
